- Cams for Twin Cam 00-06 are for use with stock splined drive gears; for installation on Twin Cam 99 motors you must purchase splined outer drive sprocket; S&S recommends that Andrews 4340 steel drive sprocket PART NO. H11-120 be used
- Cams for Dyna 06 and Twin Cam 07-10 are for use with models with hydraulic tensioner chain-drive system; cams 510C and 551C are bolt-in applications, all others require high-lift valve springs
- Made in the U.S.A.
NOTE:
- Installer must check coil bind, valve-to-valve clearance and valve-to-piston clearance
585C
- Designed for 88 in. to 95 in. engines with compression ratios from 10 to 10.5:1 and 100 in. and 107 in. engines with ratios 9.7:1 to 10.5:1
- Intake:
- Open: 20 degree
- Close: 45 degree
- Duration @ .053: 245 degree
- Valve Lift: .585
- Exhaust:
- Open: 60 degree
- Close: 20 degree
- Duration @ .053: 260 degree
- Valve Lift: .585
Included Items:
(2) Chain drive cams (1) front, (1) rear
(2) 25x32x3 Needle bearings
(2) Small O-rings
(1) Large O-ring
(1) Cam cover gasket
(1) 5ml Tube of loctite® 262
(1) 5ml Tube of loctite® 243
Instructions
The Air Resources Board (ARB) does not permit the use of aftermarket emission-related parts that alter the air/fuel ratio of an emission-controlled vehicle. Due to these legal restrictions this part cannot be shipped to California.
